In-line moisture meter HZX400

The HZX400 works on the principle that moisture (water) discretely absorbs certain wavelengths of infrared light. By emitting light at these wavelengths onto the product and then capturing and measuring the reflected unabsorbed light on a light-sensitive detector, the HZX400 computes the level of the moisture within the product. It can be used to measure pharmaceuticals, chemicals, textiles, foods, paper, minerals. In fact, almost any solid can be accurately measured.

LAST NEXT

PRODUCT DETILS

Features:

Some of the applications being successfully measured include:

* Wood Products - pulp, chips, fiber, and sludge

* Food - Processed, baked, ground, mixed, and ingredients

* Paper - All weights and grades, coated and uncoated

* Chemicals - Pellets, powders, blocks, chips and slurries

* Minerals - Powders, pellets, concentrates, and sludge

* Pharmaceuticals - Pills, capsules, powders, and raw materials

Specifications:

Display: 5 digits red LED
Measuring range: 0-80% (the maximum measuring range of the material is water absorption saturation)
Operating conditions:
Temperature:-30-50℃
Humidity:5%-90%
Resolution: 0.1 (optional 0.01)
Static accuracy: ±0.1%

Measuring accuracy: ±0.1%~0.5%

Measuring channel: 50

Height range: 250mm±100mm

Repeatability: 0.1%

Response time: 0.1-10 seconds

Filtering range: 0-2.5%

Power supply:
A.C 220V 50/60Hz, max. 50W
Dimensions:
main unit: 320mm×285mm×110mm

probe: 310mm×180mm×150mm
Weight:13kg
Guarantee:1 year
